028336:Pex-b water heater water pipe oxygen resistance floor heating tube capillary tube
Unit:
roll
Price:
C $339.00
Weight:
25.00kg
QTY:
Out Of Stock


Similar products

028291:Pex Tubing Oxygen Barrier O2 EVOH Red(20*2.0 300meter)

053248:1/2" Floor Manifold Stainless Steel Radiant PEX Floor Heating Set with Flow Meters 2-12 Loop (3 Branches)

170397:EAS Store Security System kit 3

053243:Water Separator(8 branches)

053265:Water Separator(6 Branches)

新建网页 1 新建网页 1 https://topseller365.com/data/prd/056/348/K1.jpg

3/4"*500ft EVOH PEX-B Radiant Heat Tubing

https://topseller365.com/data/prd/028/336/6.jpg
Product Overview
This Oxygen Barrier Radiant PEX-B tubing in Red is 500 feet long and is 3/4 inch. It is is commonly used for plumbing, radiant & hydronic systems, can be used in most radiant heating installation method such as Thick/Thin concrete slabs, under -sub-floor, Hanging Floor, Snow Melting and solar heating applications.
It is quick to install, flexible and used on hot/cold potable water lines. EVOH oxygen barrier layer, prevent O2 from penetrating into tubing system.
Product Parameters
Material: PEX-B(Oxygen Barrier)
Color: Blue
Total Length: 500ft
Nominal Diameter: 3/4"
Inside Diameter: 0.681"
Outside Diameter: 0.875"
Tube Thickness: 0.097"
Temperature Range: -45℃ to 110℃(-47℉ to 230℉)
Pressure Rate: 188-217psi at 20℃; 101-108psi at 95℃
Min. Bending Radius: 7"(17.8cm)
Coiled: Yes
Packing Size: 27.9"*27.6"*9.8"(71cm*70cm*25cm)
Gross Weight: 33.7lb(15.3kg)
Product Features & Advantages
- 3/4 "x 500' PEX anti UV Tubing with specifications of 22.2x2.5,keep quick & constant hot/cold water flows. Big pressure capacity: 188-217psi at 20℃; 101-108psi at 95℃. Temperature Range: -45 to 110℃(-47℉ to 230℉).
- It is covered by EVOH, which would block the O2, making the metal components anti-corrosion, to the maximum extent, lengthened the life span of the heating system. The inner pipe is smooth and anti-scalling, endowing the product with high heat diffusion efficiency and perfect energy-saving performance.
- Compatible with different connection system & floor type, such as: Crimp connection system (crimp tool + crimp rings + crimp fittings); Cinch (clamp) connection system (cinch tool + St. steel clamps + crimp fittings); Press system (by Viega); Compression PEX Fittings.
- Min.7" bending radius, this radiant floor heating system is easy to bend for different ground situation.
- Multi-use water pipe, applied for plumbing, radiant & hydronic systems, and potable water transmission. Keep quick hot & cold water flows.
Product Presentation & Details
https://topseller365.com/data/prd/028/336/4.jpg

https://topseller365.com/data/prd/028/336/12.jpg https://topseller365.com/data/prd/028/336/11.jpg
https://topseller365.com/data/prd/028/336/10.jpg https://topseller365.com/data/prd/028/336/13.jpg

https://topseller365.com/data/prd/028/336/5.jpg https://topseller365.com/data/prd/028/336/7.jpg
https://topseller365.com/data/prd/028/336/8.jpg https://topseller365.com/data/prd/028/336/3.jpg

https://topseller365.com/data/prd/028/336/14.jpg
Item Included(028336)
A Set of 3/4"*500ft EVOH PEX-B Radiant Heat Tubing
