Polyurethane Foam Spray Machine 220V

This product is mainly used for the production of semi-rigid polyurethane products, with spraying and pouring functions.
This machine is provided with left and right two independent material boxes. Two different liquid materials enter two ring piston metering pumps from the two material boxes respectively, the motor is started, the two metering pumps are driven through the gearbox, and the two liquid materials are respectively conveyed to the nozzle at the same time according to the preset proportion of a single group. The liquid material is atomized through the compressed air, so that the liquid material is evenly sprayed to form the required product.

Rated voltage: 220V
Motor power: 0.55KW * 2
Proportional pumps: 2PCS
Raw material output: 6L/min per pump
Black and white tank: Heatable
Total power: 4KW
Black and white material ratio: 1:1
Pipe length: 10 meters
Spray gun: washable spray gun
Air source :0.55MPa ~ 0.8MPa, air output ≥0.9 M3/Min
Heating method: black and white materials are heated by 1kw heating rod, white materials (15-20℃) and black materials (30-40℃)
Time control: when quantitative injection is conducted, the flow is determined, and the time relay timing value is set; when spraying is conducted, the time relay is set to 0, and the nozzle is controlled to start and stop.

1. Measurement accuracy: Due to the use of low-speed and high-precision metering pumps, when the material temperature, pressure and viscosity fluctuate, the mixing ratio is unchanged, and the highest accuracy can be achieved.

2. A and B components of the stock liquid are stirred at a high speed at the ratio and respectively transported to the mixing head by the two high-precision metering pumps. After compressed air atomization is conducted, the material liquid is sprayed evenly to form the required product.

3. The spray gun has a simple structure, reliable performance and easy operation. Spray mist and uniform foaming are achieved.

Details:

Product display:

You can make order with no worry.
Any concerns just feel free to let us know, we'll reply in 24 hours in normal condition.
Handling Time: Shipping is usually made in 1-3 business days after payments cleared. Orders are processed from Monday-Friday; Not on the weekends & public holidays.
Warranty: 6 months' warranty for the machines, not for the consumables.
We stand behind our products all the item, so even if your warranty period has expired, you can still seek for service or technical support from us with low cost.
