Roast Duck Embryo
Drying Cabinet Commercial Single-door Air-drying Cabinet 110V |
|
|
|
|
|
|
 |
|
Product
Overview |
|
The roast duck embryo drying cabinet is a food
processing device specifically designed for poultry roasting
pretreatment. By means of precision control over the
temperature, humidity and ventilation, the roast duck embryos
have even and dry skins to be in an ideal embryo state. Compared
with the traditional natural air-drying technology, the drying
cabinet has the advantages of achieving precise temperature and
humidity control, efficient sterilization and integrated design,
effectively improving the production efficiency and drying
quality, and reducing the labor cost and food waste. The roast
duck embryo drying cabinet supports partition drying, is
suitable for fresh and frozen food such as chicken embryos, duck
embryos, goose embryos, cured meat and fishes and can be widely
applied to roasted meat restaurants, fast food restaurants,
sauced meat shops, hotels, food processing plants, etc. |
|
|
Product
Parameters |
|
Power supply |
110V 50/60Hz |
|
Temperature display range |
-19˚C ~ 99˚C |
|
Temperature display accuracy |
±1˚C |
|
Temperature range |
5˚C ~
20˚C |
|
Humidity display range |
00 ~ 99% |
|
Humidity display accuracy |
±3% |
|
Working environment temperature |
-10˚C ~ 60˚C (14˚F ~ 140˚F) |
|
Relative humidity |
20% ~ 90% (no condensation) |
|
Overall size |
70*82*208cm (27.5*32.2*81.9 inches) |
|
Net weight |
121kg (266.7Lbs) |
|
 |
|
Attention |
|
1. When installing the sensor, it shall be placed
with the metal head upward and the wire downward.
2. The temperature controller cannot be installed
in the area with water drops.
3. To prevent high-frequency interference, the
sensor leads should not be tied together with the power lines or
control lines, and should be installed separately.
4. Do not touch the fans and other running parts
during operation. |
|
|
Product
Features |
|
|
|
Control Panel
The control panel adopts the upgraded operation
system, and can achieve automatic matching and flexible
adjustment of drying parameters, thereby effectively improving
the drying efficiency and quality. The machine has four modes:
auto, heat air-drying, cryogen air-drying and keep fresh, and
more choices can be provided for customers. |
|
Refrigeration System
The high-quality compressor has good
refrigeration performance and lower noise, can work continuously
and stably and creates a safer kitchen environment. The
thickened copper pipes are adopted to achieve faster
refrigeration and regular automatic defrosting, the energy
consumption is greatly reduced, and corrosion resistance is
better. |
|
Fans
The enlarged high-performance fans are designed
to achieve uniform air blowing and low-temperature air drying,
effectively improve the air drying effect and efficiency, and
can well adapt to the oily, salty and humid working environments
during operation.
|
|
|
|
|
Storage Chamber
The storage chamber has a larger storage space,
is divided into two layers, and can easily complete air drying
of batched food. Partition air drying can perfectly meet
different drying requirements, and the space utilization rate is
higher. |
|
Stainless Steel Material
The machine body is made of thickened stainless
steel materials and high-density PU foaming layers, effectively
achieving thermal insulation and energy saving while improving
the structural strength and prolonging the service life. |
|
Glass Door
The double-layer tempered glass door allows the
user to clearly observe the drying state in real time, reduces
the door opening frequency and keeps the internal temperature
constant. The thickened sealing rubber strip improves the
sealing performance.
|
|
|
|
|
Drying Rods
The stainless steel drying rods are firm and
durable and have high load capacity. The oil receiving tray is
waterproof and rustproof, facilitating oil collection and
cleaning and keeping the internal space clean and safe.
|
|
LED Lamp
The LED lighting lamp has a lighting function,
the operator can clearly observe the internal state of the
cabinet, the practicability and convenience are greatly
improved, and the user experience can be better.
|
|
Universal Wheels
The universal wheels are designed for moving the
machine body easily and conveniently, thereby effectively
improving the movement convenience and environmental
adaptability of the machine. |
|
|
Operation
Method |
|
1. Before starting the machine, check
whether all parts are intact.
2. Connect the machine to the 110V power
supply with reliable grounding.
3. Turn on the power switch, and press
the MODE key to select the working modes as needed.
Press the SET key, the ▲ and ▼ keys to set the
temperature, humidity and time according to the food to
be dried. The machine starts working normally.
4. After use, clean all the parts
thoroughly for next use. |
|
|
|
Product
Display |
 |
 |
 |
 |
|
Item Number (033412): 1 x Roast Duck Embryo
Drying Cabinet 110V |
|
|
You can make
order with no worry.
Any concern just feel free to let us know, we'll reply in 24 hours in
normal condition.
Handling Time: Shipping is usually made in 1-3 business days after
payments cleared. Orders are processed from Monday-Friday; Not on the
weekends & public holidays.
Warranty: 6 months' warranty for the machines, not for the consumables.
We stand behind our products all the item, so even if your warranty
period has expired, you can still seek for service or technical support
from us with low cost. |
|
